HP Pavilion Gaming PCHPE h8-1270d Desktop

HP Core I5 [3rd Gen 3550] 12GB RAM – 240GB SSD – 2GB NVIDIA GT 730 + Wi-Fi [Branded] [Imported].

Product Specifications of HP Pavilion PC Desktop HPE h8-1270d

• Print
• Share
• Feedback

Show all | Hide all

Product release information

Motherboard

IPMMB-FM (Formosa)

Figure 1: Motherboard top view

• Manufacturer: Pegatron
• Form factor: uATX – 24.4 cm (9.6 inches) x 24.4 cm (9.6 inches)
• Chipset: Intel Z75
• Memory sockets: 4 x DDR3
• Front side bus speeds: 5 GT/s (FM Direct Media Interface bus)
• Processor socket: LGA 1155
• Expansion Slots:
  • 1 PCI Express x16 (Gen 3.0 for i5 and i7 Ivy Bridge processors, all others Gen 2.0)
  • 3 PCI Express x1 (Gen 2.0)
  • 1 PCI Express mini card
• For more details, see Formosa motherboard specifications.

Processor

Intel Core i5 3550

• TDP: 77W
• Operating speed: 3.3 GHz (up to 3.7 GHz turbo)
• Number of cores: 4
• Socket: LGA 1155

Processor upgrade information

• TDP: Varies by processor
• Socket type: LGA 1155 (Socket-H2)
• Motherboard supports the following processor upgrades:

Memory

4 GB

• Amount: 4 GB
• Speed: PC3-12800 MB/sec
• Type: DDR3-1600

Memory upgrade information

• Dual channel memory architecture
• Four 240-pin DDR3 DIMM sockets
• Supports the following:
  • PC3-10600 (DDR3-1333)
  • PC3-12800 (DDR3-1600)
• Non-ECC memory only, unbuffered
• Supports 1 GB, 2 GB, 4 GB and 8 GB DIMMs
• Supports up to 4 GB on 32-bit systems

NOTE:32-bit systems cannot address a full 4.0 GB of memory.

• Supports up to 32 GB on 64-bit systems

NOTE: Maximum memory shown reflects the capability of the hardware and can be limited further in the operating system.

Video graphics

NVIDIA GeForce GT545

Figure 2: Video card

Figure 3: Ports

1 – HDMI

2 – VGA

3 – DVI (dual-link)

• Interface: PCI Express x16
• Maximum resolution:
  • HDMI resolution: 1920×1080 (1080p)
  • DVI resolution (dual-link): 2560 x 1600 x 32bpp at 60Hz
  • VGA resolution (with adapter): 2048 x 1536 x 32bpp at 60Hz
• 3 GB onboard memory
• Supports Blu-ray
• Supports two displays at the same time*

* Up to 2 displays at the same time in these configurations: HDMI +DVI and HDMI +VGA (VGA through adapter cable)

Intel Graphics Media Accelerator HD Integrated graphics (DX11)

*Integrated video is not available if a graphics card or an Intel processor ending with “P” is installed.

• Integrated graphics depends on the installed processor:
  • For Sandy Bridge processors: Intel HD 2000 Graphics or Intel HD 3000 Graphics
  • For Ivy Bridge processors: Intel HD 2500 or Intel HD 4000 Graphics
• One PCI Express x16 slot (Gen 3.0)

Sound/Audio

Integrated IDT 92HD73E Audio

*Integrated audio is not available if a sound card is installed.

• 1 channel audio
• Audio codec: IDT 92HD73E
• Beats Audio support: yes

Networking

802.11 Wireless b/g/n PCI-E Mini card

Figure 4: Wireless card – top view

• Interface type: PCI-e half-length mini card
• Data transfer speeds: up to 150 Mbps
• Transmission standards: 802.11 b/g/n
• Supported antenna connections: 1
• Operating band: 2.4 GHz
• Supported security protocols:
  • WPA
  • WEP

LAN: 1000BASE-T

• Interface: Integrated into motherboard
• Technology: Atheros AR8161L
• Data transfer speeds: up to 10/100/1000 Mb/s
• Transmission standards: 1000BASE-T Ethernet

Hard drive

2 TB

• Size: 2 TB
• Interface: SATA
• Rotational Speed: 7200 RPM

CD/DVD disc drive

SuperMulti DVD Burner drive

Figure 5: Optical drive

• Interface: SATA
• Data buffer memory: 2 MB minimum
• Disc diameter: 120 mm
• Write and read speeds for supported formats and disc types are shown in this table:

Memory Card Reader

Multimedia card reader

Supports the following cards:

• Secure Digital (SD)
• Mini Secure Digital (mini-SD)
• SDHC
• Memory Stick (MS), including MS-DUO, MS-PRO, MS-PRO DUO, MS-Memory Select Function, MS ULTRA II, MS ROM
• Magic Gate MS, Magic Gate MS Pro, Magic Gate MS-DUO, Magic Gate PRO DUO
• Compact Flash (CFI), (CFII)
• IBM Microdrive (MD)
• Smart Media (SM)
• Trans flash (with an adapter)

Computer Case

Mid-size ATX

Power Supply

Internal 300W (100V-240V)

• Form factor: Internal ATX
• Total wattage: 300W
• Nominal input voltage range:
  • 100-127V/6A (50-60Hz)
  • 200-240V/3A (50-60Hz)
• Dimensions: 150mm x 140mm x 86mm (5.9 x 5.5 x 3.4 inches)
• This power supply has an LED to indicate a possible failure condition when LED is off and power is connected

I/O Ports

Top I/O ports

• USB 3.0: 2
• Microphone: 1
• Headphone: 1

Front I/O ports

• USB: 4

Back I/O ports

Figure 6: Back I/O ports

1 – S/PDIF

2 – USB 2.0: 4

3 – LAN (ethernet)

4 – USB 3.0: 2

5 – DVI-I: 1 and DVI-D: 1

6 – Audio: Center/subwoofer

7 – Audio: Line-in

8 – Audio: Rear speaker out

9 – Audio: Line-out

10 – Audio: Side speaker out

11 – Audio: Microphone

Keyboard, mouse and input devices

HP Wireless Keyboard with Beats key

NOTE: Keyboard layout and functionality may vary by country/region.

Figure 7: Top view of keyboard

• Interface: USB receiver
• Effective distance: 10 meters

Dimensions:

• Length: 460 mm (18.1 inches)
• Width: 157.4 mm (6.19 inches)
• Height: 32.8 mm (1.29 inches)
• Weight: 0.61 Kg

Special buttons:*

• Standard
• Beats key. The Beats key turns on the Beats function, which is a type of bass sound quality for the speaker.
• *Buttons are not configurable

HP wireless mouse

Figure 8: Top view of mouse

• Interface: wireless USB dongle
• Buttons: left, right, and clickable scroll wheel

Software

Titles that shipped with PC

NOTE: HP provides basic support for software that comes with the computer. For in-depth feature assistance, refer to the help section in the software or on the software vendor’s Web site.

NOTE: This support document provides specifications and component images that reflect the original design intention for all PCs of this model. Under certain circumstances, a factory or service provider may install a component that meets or exceeds the listed specification and/or appears different than the image shown.
